DIAPHRAGM NEOPRENE - 1" (1A-057)
Product Description:
DIAPHRAGM NEOPRENE - 1" (1A-057) is a heavy-duty elastomeric membrane specifically designed for Blagdon 1-inch (25mm) Air Operated Double Diaphragm (AODD) pumps.
About the Product:
Specifically designed to fit Blagdon 1" (25mm) pump models. Acts as the primary flexible barrier that separates the compressed air motor from the liquid being pumped. Ideal for pumping water, vegetable oils, mild chemicals, slurries, and wastewater.
Make: BLAGDON
Specifications:
Material: Neoprene (Chloroprene Rubber).
Pump Size: 1-inch (80 mm)
Temperature Range: -20°C to +100°C (-4°F to 212°F) .
Operating pressure: 8.6 bar (125 psi).
Displacement per Stroke: 0.475 Litres
Max Flow Rate: 180 Litres/Minute
Product Weight: 100gm
Features:
1. Universal Chemical Resistance
2. Low Friction
3. Long Cycle Life
4. Structural Support with Precision Fit
5. Standardized Geometry
Terms & Conditions:
This is a Non-Returnable product
